High density polyethylene (often called alkathene or polythene) has been used since the early 1960s. It is suitable for both potable water and wastewater services but it can only be used for cold water supply.
It is the most commonly used plastic pipe for supplying the mains water to a dwelling. HDPE Pipes and Fitting or also known as Poly pipes are used in various Industries and application notably for plumbing and waterworks. The versatility of HDPE Pipes and Fittings are the main factor for its popularity and trust among plumbers and builders.
Some of the advantages of HDPE Pipes and Fittings are :-
HDPE Pipes and Fitting do not wear, rot or rust, and are a dependable and affordable material for potable-water piping, Irri. There are different types of PE Resins and the most common one is known as PE80 and PE100. There are also different type of Nominal Pressure or PN rating for HDPE Pipe and fitting ranging from PN6, PN8, PN10, PN12.5 and PN16 which suited for each Pressure rating requirement on such applications.
There are various application, services, industries and usage of HDPE pipes and Fittings.
HDPE Pipe Usage in Waterworks
The main usage for HDPE Pipe and Fitting is waterworks pipeline. The range dimension and low cost for material and installation have made HDPE piping as the suitable option for plumbers to choose HDPE piping system to be installed in both residential and commercial waterworks application.
HDPE Pipe in Mining
HDPE Pipe also is the main choice for Mining industries as the flexibility and endurance of HDPE pipe is suitable for the high pressure and flexible application in Mining field. The larger size availability for HDPE Pipe as large as 600MM is also the main criteria for increasing usage of HDPE pipe as an alternative to be compared to much expensive steel pipe in mining industries.
HDPE Pipe in Irrigation
The versatility of HDPE Pipe with the great resistance of outdoor and above ground installation also is great within farm irrigation application. HDPE subsoil pipes and fittings are often used in irrigation works for farm and garden pipeworks in both solid and corrugated wall option.
HDPE Pipe in Sewerage System
HDPE Corrugated Sewerage Pipe are often used in the sewerage system for both commercial and residential.
HDPE Application in Oil and Gas
HDPE Electrofusion and Butt-Fusion Fitting can be installed in complicated and hard situation and setting thus HDPE pipe and fitting are often used in Oil and Gas industries. The leakproof jointing of Electrofusion and Butt Fusion ensures no leakage within the application works.
HDPE pipe and fittings applications in Malaysia
Table below illustrate the Common HDPE Properties but Manufacturers may uses differents compounds and resins in their production so the Properties for HDPE between Manufacturers may varies.
| Property | Value |
|---|---|
| Intensity ISO1183 | 0.95 gr/cm3 |
| Modulus of Elasticity | 11216 Kg/cm2 |
| Tensile Stress | 255 Kg/cm2 |
| Elongation @ Break | >600% |
| Flamibility DIN 4102 | B2 |
| Thermal Conductivity | 0.4 W/m°C |
| Deflection Temperature | 75°C |
| Softening Temperature | 85°C |
| Specific Volume Resistance | >1016 Ohm.cm |
HDPE Pipe and Fitting have been a leading choice for tubing and pipelines application due to it’s Versatility, Cost effecient, Durability and High Performances. There are three main group for Poly Ethylene Pipe i.e Low Density PE or LDPE, Medium Density PE or MDPE and High Density PE or HDPE. The commonly used in Malysia market is HDPE as the performance for HDPE is higher than the other two and the option for the Pipe’s wall thickness can be selected from their PN rating.
FUIS is the leading manufacturer of Electrofusion and Buttfusion systems in Malaysia. Our company is dedicated to providing high-quality fittings and solutions for the HDPE pipe industry.
At FUIS, we specialize in HDPE Electrofusion and Buttfusion Fitting system, which is a method of joining HDPE pipes using heat and pressure to create a seamless and durable connection. FUIS electrofusion and Buttfusion systems are the best in Malaysia, with a reputation for their reliability and durability. Our products are approved by certification bodies like SPAN Malaysia and Watermark, ensuring that they meet the highest standards of quality and safety.
Our team of experts has years of experience in the industry, and we are dedicated to providing the highest level of service and support to our customers. We believe that quality and affordability should go hand in hand, which is why we offer our products at competitive prices without compromising on quality.
HDPE pipes have much superior corrosion and abrasion-resistant which makes HDPE pipes the first choice for many applications and industries in Malaysia and the world. The flexibility, ease of installation, and high flow rate coefficient of HDPE pipes and fitting also contributed to the popularity of this material in the plumbing and piping world.
The advantages of FUIS Electrofusion and Buttfusion system :-
Norma Fish Poly PP Compression fittings are specially designed to connect PE piping system for potable and irrigation application. It makes the pipe jointing much easier with Push-Fit working principle supported with physical pipe stopper and Anti-Twist wedge. Fish Poly Compression Fittings is manufactured according to international standard BS5114, ISO7 and AS4020.
FISH PP Poly Compression Fitting Characteristic :-
Buteline has developed an extensive range of quality fittings for Polybutene-1 and Polyethylene pipes. Buteline fittings are moulded from thermoplastic and fitted with an annealed protective aluminium alloy sleeve, attached during manufacture, to provide a unique metal reinforced joint. This is where Buteline’s design stands out, the fitting design overcomes high stresses, experienced in installation and service on the tail section of the fitting, by transferring all loads applied through the pipework to the thicker body of the fitting, minimising any risk of failure. During on-site installation of the fitting, the metal sleeve ensures the correct clamping position away from the end of the pipe which maximises resistance to pull out. The Buteline Group has produced millions of these thermoplastic fittings and after many years of service, they continue to work successfully.
The advantages of using Buteline PE Pipe Fitting :-
HANSEN HDPE Compression Fitting is approved by Water Supply (Water Quality) Regulations 1989 & Water Regulation Advisory Committee (WRAS) of UK for its use in potable water, this material is superior to existing materials being used in term of strength and ability to withstand heat. The fittings are designed and comply to Sirim 11:2017 standard. Hansen HDPE Compression Fittings together with HDPE Poly pipe provide an unsurpassable potable water system in terms of quality and application. These sleek fittings are slim enough to be buried in walls and are able to withstand very high pressure.
The Test undergone by Hansen HDPE Poly Compression Fitting :-
Cew Sin HDPE pipes for water supply, HDPE for sewerage, & drainage application, poly Sub-duct for telecommunication & Electrical Cabling. HDPE material exhibits a lot of advantages over traditional materials for pressure pipe applications. The pipes are easy to install, light, flexible, corrosion free and can be easily welded by Butt fusion or Electrofusion couplers to ensure a totally leak free network. They are classified and tested according to MS 1058: Part2: 2005 and ISO 4427 for drinking water application. Creep resistance and long term strength, through the MRS classification as defined in ISO 9080. Stress cracking resistance, critical property to avoid initiation and propagation of cracks due to scratches during installation or point loading. Rapid crack propagation resistance to avoid bursting due to sudden break caused by an external stress.
Cew Sin HDPE Pipe features :-
ELGEF Plus Electrofusion Couplers join all PE pressure pipes and spigot fittings quickly and reliably. ELGEF Plus electrofusion couplers are available in the size range from d20 to d1200 mm. Couplers are grouped into various size ranges. In this way, individual dimension requirements are fully satisfied. In the smaller sizes a coupler is available which especially fulfills service line conditions. Couplers up to d63 mm can be easily matched with all GF threaded transition adapters. The advantages of using electrofusion fittings are offered up to d250 mm. From the wrapping directly onto the prepared pipe end. One fitting, one joint and the direction can be reset.
On-site cleaning becomes unnecessary due to the care and attention taken during manufacture and the sealed packaging used for all fittings. A complete installation in the sizes between d20 and d63 mm can be easily pre-assembled without any difficulty using the integrated pipe fixation. The jointing procedure is completed when everything is in its final position. The threaded adapters are screwed into position and then the direction is chosen using the fitting. This is a crucial advantage in difficult conditions.
The advantages OF ELGEF Plus Electrofusion Fitting:-
Spirolite is one of the leading High Density Polyethylene (HDPE) pipe and tank manufacturers in Malaysia. Spirolite products range include Spirolite HDPE Pipe, Spirolite HDPE Spiral Tank, Spirolite HDPE Spiral Pipe, Spirolite Ribflo HDPE Corrugated Subsoil Drainage Pipe, Spirolite SPI HDPE Corrugated Subduct, Spirolite HDPE Flap Gate, Spirolite TNB Red Pipe and Spirolite Telecom Black Pipe for various application, including water pipeline, gas pipeline, chemical pipeline, sewerage pipeline, flood and river management, storm water management and cable pipeline solution. Spirolite HDPE pipe and fitting is certified by Standards and Industrial Research Institute of Malaysia (SIRIM) and Suruhanjaya Perkhidmatan Air Negara (SPAN).
Spirolite produce HDPE pipe ranging from 20mm to 630mm outer diameter (OD) suitable for portable water pipeline and irrigation that widely accepted and recognized in terms of its quality and reliability performance. Spirolite’s major customers include state water-works authorities, infrastructure authorities, Department of Irrigation and Drainage (DID), sewerage contractors, infrastructure contractors, telecommunication service providers, housing developers and hardware wholesales dealers. Spirolite’s products are exported to Singapore, Brunei, Indonesia, Myanmar, Cambodia, Philippines, Sri Lanka and etc
Standard testing for Poly pipe system :-
